Product details
- Brand
- Brother
- Color / finish
- White / black
- Product type
- Wired network document scanner
Description
The ADS-4300N suits a permanent scanning station where a wired network connection is preferred. It captures both sides of loose documents in one pass and feeds prepared stacks automatically, helping move paper records into a shared filing system.
Its practical distinction is connectivity: this is the Ethernet-and-USB ADS-4300N, rather than a wireless touchscreen model. It is a straightforward choice when the scanner will stay near a network socket or a dedicated workstation. Check the receiving software and folder setup before relying on an unattended scan process.
Features
- 80-sheet document feeder: handles recurring batches of invoices, forms and correspondence.
- Duplex in one pass: captures both sides without asking you to reverse the stack.
- Ethernet networking: lets compatible users share the scanner through a wired network.
- USB 3.0 connection: provides a direct workstation setup when shared networking is unnecessary.
- Integration choices: TWAIN, WIA, ISIS and SANE drivers support compatible document applications.
Specifications
- Feeder
- 80 sheets
- Scan speed
- 40 ppm max.
- Weight
- 6.1 lb
| Model | ADS-4300N |
|---|---|
| Rated scan speed | Up to 40 ppm / 80 ipm; Letter at 300 dpi |
| ADF capacity | Up to 80 sheets of 20 lb paper |
| Optical resolution | 600 × 600 dpi |
| Built-in connections | Ethernet and USB 3.0; rear USB host |
| Built-in Wi-Fi | No |
| Unit size | 11.7 W × 8.5 D × 7.5 H inches before working clearance |
| Unit weight | 6.1 lb |
Choose the right wired workflow
Leave room for the feeder and output tray to extend. The compact stored dimensions do not describe the full working area with paper loaded. Remove clips and staples, straighten folded corners and avoid sending delicate originals through rollers merely because they fit the slot.
| One scanning desk | Use the USB cable with a compatible computer and scanning application. |
|---|---|
| Several users | Connect Ethernet to the office network and configure the approved destinations. |
| USB storage | Use the rear memory-stick connection for supported direct-to-drive jobs. |
| Archive quality | Set resolution and file type for the content, then check a sample before a large batch. |
What's included
- ADS-4300N scanner
- AC adapter
- USB 3.0 cable
- Quick setup guide
Common questions
Is the ADS-4300N wireless?
No. The scanner itself connects through Ethernet or USB. A phone may access a properly configured network through Wi-Fi, but that does not give this scanner a built-in wireless radio.
Does it scan both sides automatically?
Yes. Its dual image sensors support single-pass duplex scanning. Check the chosen profile so both sides are saved when needed.
Can I use it with existing document software?
Potentially: it provides common scanner drivers including TWAIN and ISIS. Confirm the driver and operating system required by your exact application before purchase.
Can I scan photographs?
Supported loose photo media can be scanned with suitable handling, but valuable, curled or fragile prints deserve extra care and may be better on a flatbed. Follow the manual for approved carrier sheets and media.
Product information & sources
Model details checked against the exact catalog listing and manufacturer references. Software, network services and operating-system support should be checked for your intended setup. Brother ADS-4300N model specifications; Brother current manuals and drivers. Reviewed September 2026.
